Gigabyte RTX 3090 Turbo 24GB Graphics Card with Turbo Fan Cooling
$447.59
Skip to product information
Gigabyte RTX 3090 Turbo 24GB Graphics Card with Turbo Fan Cooling
$447.59
SidneyGoods offers the Gigabyte RTX 3090 Turbo 24G GV-N3090TURBO-24GD graphics card for users building space-restricted systems, including closely stacked multi-graphics-card configurations. It combines metal structural components with copper cooling elements and a blower-style airflow design for compact workstation and gaming builds.
Key Features & Specs
- GPU architecture: NVIDIA Ampere Streaming Multiprocessors with 2nd Generation RT Cores and 3rd Generation Tensor Cores
- Memory: 24GB GDDR6X with a 384-bit memory interface
- Core clock: 1695 MHz
- Cooling system: Turbo fan cooling system with an 80 mm blower fan and vapor chamber direct touch GPU cooling
- Thermal components: Copper vapor chamber, heat pipe, and heat sink
- Airflow design: Inward-indented metal cover creates intake space when cards are installed close together
- Fan bearing: Double ball bearing structure
- Physical protection: Metal frame and metal back plate
- PCB protection: Aerospace-grade coating designed for dust, moisture, and corrosion resistance
- Multi-GPU support: Supports NVIDIA NVLink technology with two identical GPUs and a GeForce RTX NVLink Bridge
- Adjustment software: AORUS ENGINE supports real-time adjustment of clock speed, voltage, fan performance, and power target
How it Compares
| Feature | This Product | Why It Matters |
|---|---|---|
| GPU Model | GeForce RTX 3090 | Provides powerful graphics processing, suitable for demanding applications and gaming. |
| Cooling System | Turbo fan with vapor chamber and copper heat sink | Enables effective heat dissipation, supporting stable performance in space-restricted chassis. |
| Memory | 24GB GDDR6X, 384-bit interface | Delivers high memory bandwidth for intensive tasks like 4K gaming and content creation. |
| Core Clock | 1695 MHz | Defines the GPU's processing speed, impacting rendering and workload performance. |
| PCB Coating | Aerospace-grade; dust, moisture, and corrosion resistant | Enhances durability by protecting the card against environmental factors and accidents. |
Recommended Use Cases
- Closely stacked multi-graphics-card workstation builds where each card needs access to an intake path
- Desktop builds with restricted internal space that benefit from a blower-style airflow approach
- Two-card NVIDIA NVLink configurations using identical supported GPUs and a GeForce RTX NVLink Bridge
- Gaming systems where users want to adjust clock speed, voltage, fan behavior, and power target through AORUS ENGINE
- PC builds exposed to dusty, humid, or corrosion-prone environments where coated PCB protection is relevant
Frequently Asked Questions
Is the Gigabyte RTX 3090 Turbo 24G suitable for a high-end gaming PC in a tight case?
Yes. The Gigabyte RTX 3090 Turbo 24G is designed for space-restricted chassis, using an 80 mm blower fan and an inward-indented metal cover to maintain air intake when cards are closely positioned.
Can I use the Gigabyte RTX 3090 Turbo 24G for a workstation where multiple cards are stacked closely together?
Yes. The Gigabyte RTX 3090 Turbo 24G is described as ideal for multi-graphics-card systems with limited chassis space, and its indented cover is designed to give the intake fan room near adjacent cards.
What should I look for in a GPU for a compact PC that needs effective thermal management?
Look for a cooling layout that preserves intake airflow and transfers heat away from the GPU in restricted space. The Gigabyte RTX 3090 Turbo 24G combines a vapor chamber direct-touch GPU, copper heat sink and heat pipe, plus a double ball bearing blower fan.
Is the Gigabyte RTX 3090 Turbo 24G a good option for users who want to tune graphics card settings?
Yes. AORUS ENGINE allows real-time adjustment of clock speed, voltage, fan performance, and power target according to game requirements.
